Infinia Frag 125.4 (78 gallon)- Drop Ship

The Waterbox INFINIA Series represents the pinnacle of luxury and performance in reef-ready aquarium systems. Designed for advanced aquarists and marine enthusiasts who demand the highest quality, the INFINIA offers a meticulously engineered platform that combines modern elegance with industry-leading functionality.

Each INFINIA aquarium is constructed from ultra-clear, low-iron Starphire glass for unparalleled clarity and a seamless, rimless viewing experience. The system features a full-sized, high-capacity glass sump, professional-grade plumbing, and a marine-grade aluminum framed cabinet with soft-close doors and integrated ventilation. Every detail is designed with performance, durability, and aesthetics in mind.

Key Features:

• Ultra-Clear Glass Construction
  Built with ultra-clear, low-iron glass and precision-polished edges for optimal viewing and lasting durability.

• Rimless, Open-Top Design
  A sleek, modern silhouette that enhances any environment, while offering full access to your aquascape.

• Reef-Ready Overflow System
  Integrated overflow with dual returns ensures efficient, quiet water circulation and maximum surface skimming.

• Advanced Filtration
  High-volume glass sump includes filter socks, adjustable water height, and a dedicated RO reservoir, supporting top-tier mechanical and biological filtration.

• Professional Plumbing Kit
  Pre-assembled, color-coded Schedule 40 PVC plumbing provides fast installation and long-term reliability.

• Aluminum-Framed Cabinetry
  The INFINIA stand is built with a marine-grade aluminum frame, resistant to moisture, corrosion, and salt creep. Soft-close doors, adjustable feet, and internal access panels complete the system.

Why Choose Waterbox INFINIA?

The Waterbox INFINIA is more than just an aquarium—it's a statement piece. Designed for serious reefers and aquascapers, it offers an ideal balance of premium craftsmanship, advanced functionality, and clean, modern design. Whether you're building a high-end reef or a large freshwater planted system, the INFINIA provides the professional-grade platform to support it.

Waterbox INFINIA – Limitless Design. Infinite Possibilities.



PEACE OF MIND

3 Year Waterbox Warranty warrants your product against defects in materials and workmanship for a period of 3 years, valid from the original date of purchase.

Specifications

• Dimensions (LxWxH): 1223 x 643 x 410mm (48.2" x 25.3" x 16.1")
• Height with Cabinet: 1,337 mm / 52.6"
• Display Volume: 295 L / 78 gal
• Total Volume: 473 L / 125 gals
• Glass Thickness: 12 mm (1/2")
• Includes: Aquarium, Cabinet, Sump, Plumbing Kit, Filter Socks, Sock Silencers




Technical Specifications



Product Model		INFINIA FRAG 125.4	INFINIA FRAG 155.5	INFINIA FRAG 175.6
System	Height with Cabinet	1,337mm/52.6"	1,337mm/52.6"	1,337mm/52.6"
	Total Volume with ATO	469 L/123.8 gals	585 L/154.6 gals	690 L/182.2 gals
	Total System Weight	175 kg/386 lbs	211 kg/465 lbs	232 kg/511 lbs
Display Tank	Tank Dimensions	1,223 x 643 x 410mm	1,536 x 643 x 410mm	1,836 x 643 x 410mm
		48.2" × 25.3" × 16.1"	60.5" × 25.3" × 16.1"	72.3" × 25.3" × 16.1"
	Glass Thickness	12mm (1/2")	12mm (1/2")	12mm (1/2")
	Aquarium Volume	295 L/78 gals	372 L/98.4 gals	446 L/117.9 gals
	Aquarium Weight	82 kg/181 lbs	98 kg/216 lbs	113 kg/249 lbs
	Glass Material	Ultra-clear Low Iron glass (front and sides)
	Transmittance	91%
In-cabinet Sump	Dimensions	864 x 475 x 380mm	1,067 x 475 x 380mm	1,143 x 475 x 380mm
		34" × 18.7" × 15"	42" × 18.7" × 15"	45" × 18.7" × 15"
	Sump Volume	140 L/37.1 gals	162 L/42.8 gals	192 L/50.8 gals
	Sump Weight	40 kg/88 lbs	45 kg/99 lbs	48 kg/106 lbs
	Glass Thickness	8mm (5/16")
	Refugium Chamer (Max Int. Dimensions)	180 x 400mm	250 x 400mm	300 x 400mm
		7.1" × 15.8"	9.8" × 15.8"	11.8" × 15.8"
	Refugium Chamer (Min Int. Dimensions)	140 x 400mm	200 x 400mm	230 x 400mm
		5.5" × 15.8"	7.9" × 15.8"	9.1" × 15.8"
	Skimmer Chamber (Int. DIM, w/o Refugium)	416 x 400mm	528 x 400mm	676 x 400mm
		16.4" × 15.8"	20.8" × 15.8"	26.6" × 15.8"
	Skimmer Chamber (Int. DIM, with Min Refugium)	271 x 400mm	323 x 400mm	441 x 400mm
		10.7" × 15.8"	12.7" × 15.8"	17.4" × 15.8"
	Skimmer Chamber (Int. DIM, with Max Refugium)	231 x 400mm	273 x 400mm	371 x 400mm
		9.1" × 15.8"	10.7" × 15.8"	14.6" × 15.8"
	Pump Chamber (Int. Dimensions)	135x 400mm	150 x 400mm	180 x 400mm
		5.3" × 15.8"	5.9" × 15.8"	7.1" × 15.8"
ATO Tank	ATO Dimensions	203 x 475 x 380mm	305 x 475 x 380mm
		8" × 18.7" × 15"	12" × 18.7" × 15"
	ATO Volume	33 L/8.7 gals	51 L/13.4 gals
	ATO Weight	9 kg/20 lbs	11 kg/24 lbs	11 kg/24 lbs
	Glass Thickness	6mm (1/4")	6mm (1/4")
Plumbing	Main Drain	DN32 (ID: 32mm OD: 40mm)
	Emergency Overflow	DN32 (ID: 32mm OD: 40mm)
	Pump Return	DN25 (ID: 25mm OD: 32mm)
	Return Hose	lD: 25mm OD: 31mm
	Nozzle(s) (Thread Size)	2 x M25 (25mm)
	Manifold Kit	Manifold 15 (Single outlet)
Filtration	Filter Socks	2 x 180mm/7" FELT
	Filter Sock Silencers	2 x 180mm/7"
	Interchangable with Roller Filter	YES
Marine- Shield Cabinet	Cabinet Model	MSII 4825	MSII 6025	MSII 7225
	Cabinet Dimensions	1,223 x 643 x 927mm	1,536 x 643 x 927mm	1,836 x 643 x 927mm
		48.2" × 25.3" × 36.5"	60.5" × 25.3" × 36.5"	72.3" × 25.3" × 36.5"
	Sump Compartment (Int. Dimensions)	1182 x 549 x 849mm	1,495 x 541 x 849mm	1,795 x 541 x 849mm
		46.5" × 21.6" × 33.4"	58.9" × 21.3" × 33.4"	70.7" × 21.3" × 33.4"
	Cabinet Framework	Anti-corrosion Aluminum Alloy
	Door Panels	Double-sided 18mm PET laminated Wood Oriented Strand Board
	Side Panels	Aluminum Composite
	Bottom Panels	10mm PVC Board
	Back Panels	5mm PVC Board
	Cabinet Weight	44 kg/97 lbs	57 kg/126 lbs	60 kg/132 lbs
	Cabinet Color	WHT-White, BLK-Black
